Relay technology has become an essential component in modern electrical and electronic systems, providing a reliable means of control and automation. A relay is an electromechanical device that acts as a switch, using a small electrical current to control a larger electrical circuit. This article delves into the principles of relay operation, various types of relays, their applications, and the advantages they offer in different contexts.
At the fundamental level, a relay consists of an electromagnet and a set of contacts. When a low-voltage signal is applied to the electromagnet, it creates a magnetic field that attracts an armature, causing it to move and either open or close the contacts. This allows the relay to control a larger load without directly connecting the high-voltage supply to the control circuit, thus providing electrical isolation. The ability to use a small input current to control a larger output current is one of the significant advantages of relay technology. There are several types of relays, each designed for specific applications. The most common types include：
