In the realm of electrical engineering, the role of protective devices is paramount in ensuring the efficient and safe operation of electrical machinery. One such critical component is the Motor Overload Relay (MOR), which provides vital protection to electric motors against overheating and overcurrent conditions. This article delves into the functions, types, benefits, and maintenance of motor overload relays, highlighting their significance in various applications.
Functionality of Motor Overload Relay The primary function of a Motor Overload Relay is to prevent electric motors from operating under damaging conditions. Electric motors are often subjected to varying loads, and when these loads exceed the motor’s rated capacity, the resultant current can lead to overheating. This overheating may cause insulation failure and ultimately result in motor burnout. The MOR monitors the current flowing to the motor and disconnects it when it exceeds a predetermined threshold, thereby protecting the motor from damage. Types of Motor Overload Relays Motor Overload Relays generally fall into two main categories：
